577nm激光器

产品说明：577nm激光器 LL577-3500mw LD PUMPED ALL-SOLID-STATE YELLOW LASER AT 577nm All solid state 577 nm yellow laser is made features of ultra compact long lifetime and easy operating which is widely used in collimation laser medical treatmen

订购热线：0431-81759561

产品详细

577nm激光器
LL577-1200mw

LD PUMPED ALL-SOLID-STATE YELLOW LASER AT 577nm All solid state 577 nm yellow laser is made features of ultra compact, long lifetime and easy operating, which is widely used in collimation, laser medical treatment, scien

Part number	LL577-1200mw
Wavelength (nm)	577±2
Operating mode	CW
Output power (mW)	600- 1200
Power stability (rms, over 4 hours)	<3%, <2%, < 1%
Transverse mode	Multi mode
M2 factor	<2.0
Beam diameter at the aperture ( 1/e2, mm)	<2.5
Beam divergence, full angle (mrad)	< 1.5
Polarization Ratio	> 100:1, (Horizontal or Vertical Optional)
Warm-up time (minutes)	<5
Pointing stability after warm-up (mrad)	<0.05
Beam height from base plate (mm)	27.4
Operating Temperature (°C)	10-35
Modulation option	TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz
Power supply (90-264VAC)	PSU-H-LED
Expected lifetime (hours)	10000
Warranty	1 year
