405nm激光器| Central wavelength (nm)中心波长 | 405±5 | |
| Output power@3.3VDC (mW, CW)输出功率 | >1, 10, 20, … ,200 | >200, 300, … ,500 |
| Power adjustable by software | ||
| Power stability (rms, over 4 hours)功率稳定性 | <3%, <2%, <1% | |
| Pulse width (FWHM)脉宽 | >10ns, 20ns, … , 10ms | >12ns, 13ns, … , 10ms |
| Transverse mode光斑模式 | Near TEM00 | |
| Noise of amplitude(rms, CW)噪声 | <1% | |
| M2 factor光束质量 | <1.2 | |
| Beam diameter at the aperture (1/e2,mm)光斑 | ~ 1.2 | |
| Beam divergence, full angle (mrad)发散角 | <1.0 | |
| Polarization ratio偏振比 |
>50:1 (>100:1, optional) Horizontal±5 degree (Vertical Optional) |
|
|
User trigger frequency 频率 (Multifunctional Pulse Trigger optional) |
1Hz-80MHz | 1Hz-45MHz |
| 1Hz-25MHz by using CNI Multifunctional Pulse Trigger | ||
| Rise Time (ns)上升时间 | <3 | <7 |
| Fall Time (ns)下降时间 | <3 | <3 |
| Modulation Depth (extinction ratio) | >1000000:1 | |
| Warm-up time (minutes)预热时间 | <5 | |
| Beam height from base plate (mm)中心高 | 19 | |
| Operating temperature (℃)工作温度 | 10~35 | |
| Input voltage供电 | +12VDC | |
| Expected lifetime (hours)寿命 | 10000 | |
| Warranty保修 | 1 year | |
