532nm单纵模激光器

产品说明：532nm单纵模激光器 LLDZ532-100mw SINGLE LONGITUDINAL MODE GREEN LASER AT 532 nm All solid state single longitudinal mode green laser at 532 nm is made features of ultra compact long lifetime low cost and easy operating which is used

订购热线：0431-81759561

产品详细

532nm单纵模激光器
LLDZ532-100mw

SINGLE LONGITUDINAL MODE GREEN LASER AT 532 nm All solid state single longitudinal mode green laser at 532 nm is made features of ultra compact, long lifetime, low cost and easy operating, which is used in DNA sequencing, flow cytometry, cell sorting, optical instrument, spectrum analysis, interference, measurement, holography, brillouin scattering, physics experiment, etc.

Wavelength (nm)波长	532±2
Operating mode	CW
Output power (mW)	> 100
Power stability (rms, over 4 hours)	<3%
Transverse mode	TEM₀₀
Longitudinal mode	Single
Spectral linewidth (nm)	<0.00001
Coherent length (m)	>50
Noise of amplitude (rms, 1Hz~20MHz)	<0.5%
M2 factor	<1.2(<1.1 optional)
Beam diameter at the aperture (1/e2, mm)	<1.5
Beam divergence, full angle (mrad)	<1.2
Polarization ratio	>100:1, Vertical±5 degree (Horizontal Optional)
Warm-up time (minutes)	<10
Pointing stability after warm-up (mrad)	<0.05
Beam height from base plate (mm)	24.8
Operating temperature (℃)	15~35
Expected lifetime (hours)	10000
Warranty	1 year
