Operating mode工作方式

Pulsed

Output power (mW)输出功率

100

200

300

Power stability (rms, over 4 hours)功率稳定性

<5%, <3%

Pulse width (ns) 脉宽

One fixed value between 0.5-50ns

M2 factor光束质量

<2

Repetition frequency (MHz)频率

One fixed value between 0. 1-1MHz

Polarization ratio偏振比

> 15dB

Warm-up time (minutes)预热时间

<15

Delivery cable length(cm)

60

Operating temperature (℃)工作温度

15~35

Power supply供电

12V DC

Expected lifetime (hours)寿命

10000

Warranty保修

1 year

Options

(1)  Pulse width 0.5~5ns or 5~50ns variable

(2)  0. 1~ 1MHz variable

RS 232 interface

Higher output power can be customized
